ARC
ARC（LCD）
LCD ARC welder/ MMA welder / SMAW welder / Stick welder / ARC welding machine
● Product Parameters
| Model | ARC-120LCD | ARC-160LCD | ARC-180LCD | ARC-200LCD | ARC-230LCD |
| Rated Input Voltage(V) | 1P 220V | 1P 220V | 1P 220V | 1P 220V | 1P 220V |
| Rated Input Current(A) | 36 | 36 | 41 | 46 | 51 |
| Input Capacity(KVA) | 3 | 5.1 | 8.1 | 9 | 10.1 |
| Inverter Frequency(KHz) | 40 | 40 | 40 | 40 | 40 |
| No-Load Voltage(V) | 65 | 78 | 78 | 78 | 78 |
| Duty Cycle(%) | 25 | 30 | 30 | 30 | 30 |
| Current Range(A) | 20-120 | 20-160 | 20-180 | 20-200 | 20-220 |
| Recommend Electrode Diameter(MM) | 1.6-3.2 | 1.6-3.2 | 1.6-4.0 | 1.6-4.0 | 1.6-5.0 |
| Efficiency(%) | 85 | 85 | 85 | 85 | 85 |
| Insulation Class | F | F | F | F | F |
| Real Current(A) | 120 | 160 | 180 | 200 | 220 |
| Dimension(MM) | 240*90*140 | 305*130*245 | 325*160*280 | 325*160*280 | 325*160*280 |
| Weight(KG) | 2.2 | 3.75 | 4.95 | 4.95 | 5.3 |
